In many offices use is made of a system ceiling. This makes it no sight to place a large sensor there. Steinel has developed the IS D 360 for this. The IS D 360 is a built-in sensor that is very similar to the average downlight. With a saw diameter of 6.6 centimeters, it fits in almost every spa holder. The 360 ??degree sensor works best up to a maximum height of 2.5 meters. The sensor is of the infrared type, which means that the lamps only go on when they see the movement of heat. Up to a maximum of 1000 watts you can connect a number of lamps in 1 room to the same sensor. As a result, the room is completely illuminated in one go instead of every time a light comes on every few steps. For the low ceilings, Steinel has made the IS D 360 so smart that it can be adjusted in various ways. Even the switch-on brightness can be set from 2 to 2000 lux. The lamp does not work during the day, but is taken out of its sleep mode when it gets dark. If you find that he is awakened too early or too late, you can easily adjust it with this setting. In addition, the time can also be set to a maximum of 20 minutes. You do not have to worry that the lighting goes off every 20 minutes, because the IS D 360 from Steinel also has a permanent stand of up to 4 hours.

IS D 360 Motion Sensor for Complex Spaces

The IS D 360 from Steinel is an advanced motion sensor specifically designed for complex spaces. With its innovative technology and user-friendly settings, this sensor offers a reliable solution for automatically activating lighting based on movement.

Sensor Features

The IS D 360 is equipped with a powerful built-in sensor capable of detecting a 360° angle, with an impressive range of up to 8 meters. This infrared sensor responds to the body heat of people, effectively excluding disturbances such as wind, leaves, rain, and small animals. The 360° detection angle combined with a 180° opening angle ensures that the sensor can cover a wide area. Additionally, the sensor can rotate horizontally up to 80° via a pivot sensor, enhancing installation flexibility.

Sensor Settings

One of the key features of the IS D 360 is the ability to adjust the light sensitivity. With a convenient adjustment knob, the ambient light intensity at which the sensor light is activated can be continuously set from 2 lux to 2000 lux. This means you only turn on the lighting when truly necessary. After detecting movement, the light remains on for a customizable duration, ranging from 5 seconds to as much as 20 minutes. This adjustment ensures that you always have the right amount of light exactly when you need it.

Additional Features

The IS D 360 has an IP rating of IP20, meaning it is suitable for use in dry indoor spaces. For optimal performance, it is recommended to mount the sensor at a height of 2.5 meters. This ensures that the sensor can utilize its full potential and maintain a wide range.

Why Choose the IS D 360?

• Advanced infrared technology for reliable detection
• Adjustable light sensitivity from 2 lux to 2000 lux
• Flexible installation with 80° horizontal rotation
• Customizable duration from 5 seconds to 20 minutes
• Ideal mounting height of 2.5 meters for optimal performance

With the IS D 360, you are assured of an efficient and reliable solution for all your lighting needs in complex spaces. Thanks to the smart technology and adjustable options, this motion sensor adapts to your specific situation, ensuring you can always count on the right lighting.
