Description

This IS 2160 ECO is the 160 ° infrared motion detector with max. 12 m reach for wall mounting inside and outside. This IS 2160 ECO monitors with a 160 ° registration angle and a range of up to 12 m surfaces up to 170 m². The multilens divides the registration area. The total switching capacity is 600 W, the time and start level of the infrared motion detector can be individually controlled. Light ON / OFF - automatically. The highly innovative sensors react to movements and light conditions and automatically switch the light on and off after a configurable time. Living comfortably and at the same time saving energy. More quality of life, safety and energy savings thanks to intelligent sensor technology from STEINEL. Technical data Infrared motion detector IS 2160 ECO white European Article Number: (EAN) 4007841606015 Execution: Motion detector Dimensions: (H x W x D) 113 x 78 x 73 mm Power supply: 230 - 240 V, 50 Hz Sensor type: Passive infrared Application: inside and outside Mounting: Wall recommended installation height 2.00 m max. power (ohmic load, eg lamp for universal use) 600 W max. power (uncompensated, inductive, cos? = 0.5, eg fluorescent lamps) 500 VA max. power (series compensated) 500 W max. power (parallel compensated, with C? 45.6 ?F) 500 W max. power (electronic ballasts, capacitive, eg energy-saving lamps) max. 4 pcs., C? 88 ?F Angle of registration: 160 ° with 40 ° opening angle reduction of the registration angle per segment possible Yes Swivel range horizontal: 40 ° Swivel range vertical: 70 ° Range max. 12 m Sensor 5 registration levels 260 switching zones Switch-on strength 2-2000 lx Time setting 8 sec. - 35 min. IP54 protection (IP) Protection class II Temperature range -20- + 50 ° C Variant: white

Steinel IS2160 Motion Sensor

The IS2160 is an advanced motion sensor from the brand Steinel, perfect for automatically turning on lighting when needed. This sensor not only offers convenience but also an energy-efficient solution for your lighting needs.

Sensor Features

The IS2160 ECO is available in both white and black, allowing it to be integrated into various environments. The sensor can be connected to a light source of up to 600W, making it suitable for different applications. With a detection angle of 160° and a range of up to 12 meters, this sensor is highly efficient in detecting movement. The infrared sensor responds to the body heat of people, eliminating disturbances such as wind, leaves, rain, and small animals.

The sensor also features a swivel sensor, allowing it to rotate 40° horizontally and 70° vertically. This ensures that you can optimize the detection angle for your specific situation.

Sensor Settings

With the IS2160 ECO, you can easily set the ambient light level at which the sensor light should be activated. The adjustment knob allows you to set the activation level continuously from 2 lux to 2000 lux. Once movement is detected, the light stays on for the set duration. The time setting is flexible and can be adjusted from 8 seconds to 35 minutes, so you can choose the perfect settings for your needs.

Additional Features

The IS2160 ECO is made from UV-resistant plastic, ensuring a long lifespan even in challenging weather conditions. With an IP rating of IP54, this sensor is well protected against dust and splashes. For optimal performance, it is recommended to install the sensor at a height of 2 meters.

Why Choose the IS2160?

• Efficient motion detection with a range of 12 meters
• Adjustable light intensity and duration for maximum flexibility
• Robust construction with UV-resistant materials
• Easy installation and adjustment of the detection angle

With the Steinel IS2160, you not only bring home a reliable sensor but also a smart solution for your lighting. This sensor is ideal for both indoor and outdoor applications, providing you with peace of mind that your lighting will always turn on when needed.
