Steinel - Motion sensor IS 3180-E PF AP WS
Now: 187.97 (+ accessoires)
3 - 5 working days
Advantages:
Description
These sensors are just right when it comes to the protection and safety around industrial and commercial buildings. Attentive caretakers who respond immediately to every movement are therefore important. The IS 3180 is the designated guard for this. Thanks to the IP 54, the inner values ??are well protected: with amazing components such as two precise pyro sensors and a multilens, which can be modularly mounted, it monitors surfaces up to more than 500 m² almost completely. The surface-mounted sensor that unites everything, which is important for installers and safety employees. European Article Number (EAN) 4007841010508 Implementation Motion detector Sensor type Passive infrared Angle of registration 180 ° with 90 ° opening angle Scope Basic setting 1: 8 - 20 m Basic setting 2: 4 - 8 m recommended mounting height 1.8-2.5 m Dimensions (H x W x D) 95 x 95 x 65 mm Power supply 220 - 240 V, 50 / 60Hz Power 50-240 V, 10 A Self-learning function for response clarity yes Time setting 5 sec. - 15 min. impulse mode (approx. 2 sec.) Response brightness 2-1000 lx Degree of protection (IP) IP54 Temperature -20-50 ° C Housing UV-resistant plastic Model Potential free Variant Potential free - Building square
IS 3180-E PF AP WS Motion Detector
The IS 3180-E PF AP WS from Steinel is an advanced motion detector that is perfect for both indoor and outdoor applications. With its powerful functionality and smart design, this sensor provides a reliable solution for automatically turning on lighting when needed.
Sensor Features
This motion detector is equipped with a built-in infrared sensor that registers movements at an angle of 180 degrees, up to a distance of 20 meters. The sensor responds not only to movement but also to the body heat of people, effectively excluding disturbances such as wind, leaves, rain, and small animals. This makes the IS 3180 particularly suitable for use in various environments.
Adjustable Sensor Settings
To ensure that the lighting only activates when truly necessary, the IS 3180 features adjustable ambient light sensitivity. With a convenient adjustment knob, the activation level can be set continuously from 2 lux to 2000 lux. This means you can tailor the lighting to the specific light conditions of your environment.
Additionally, you can adjust the time setting so that the light remains on for a certain period after detecting movement. The time setting is adjustable from 5 seconds to 15 minutes, providing a flexible and user-friendly experience.
Other Features
- Maximum load:2000W
- IP rating:IP54, meaning the sensor is resistant to dust and splashes
- Ideal mounting height:2 meters
With the IS 3180-E PF AP WS, you are assured of a reliable and efficient motion detector that optimizes your lighting and saves energy. This product is an excellent choice for anyone looking for a smart solution for their lighting needs.
Specifications
- Product number 68026
- Manufacturer product number 10508
- Material Plastics
- IP value 54
- Warranty 2
- Color White
- Dimensions (W) x (H) x (D) : 9.5 x 9.5 x 6.5 cm
These sensors are just right when it comes to the protection and safety around industrial and commercial buildings. Attentive caretakers who respond immediately to every movement are therefore important. The IS 3180 is the designated guard for this. Thanks to the IP 54, the inner values ??are well protected: with amazing components such as two precise pyro sensors and a multilens, which can be modularly mounted, it monitors surfaces up to more than 500 m² almost completely. The surface-mounted sensor that unites everything, which is important for installers and safety employees. European Article Number (EAN) 4007841010508 Implementation Motion detector Sensor type Passive infrared Angle of registration 180 ° with 90 ° opening angle Scope Basic setting 1: 8 - 20 m Basic setting 2: 4 - 8 m recommended mounting height 1.8-2.5 m Dimensions (H x W x D) 95 x 95 x 65 mm Power supply 220 - 240 V, 50 / 60Hz Power 50-240 V, 10 A Self-learning function for response clarity yes Time setting 5 sec. - 15 min. impulse mode (approx. 2 sec.) Response brightness 2-1000 lx Degree of protection (IP) IP54 Temperature -20-50 ° C Housing UV-resistant plastic Model Potential free Variant Potential free - Building square
IS 3180-E PF AP WS Motion Detector
The IS 3180-E PF AP WS from Steinel is an advanced motion detector that is perfect for both indoor and outdoor applications. With its powerful functionality and smart design, this sensor provides a reliable solution for automatically turning on lighting when needed.
Sensor Features
This motion detector is equipped with a built-in infrared sensor that registers movements at an angle of 180 degrees, up to a distance of 20 meters. The sensor responds not only to movement but also to the body heat of people, effectively excluding disturbances such as wind, leaves, rain, and small animals. This makes the IS 3180 particularly suitable for use in various environments.
Adjustable Sensor Settings
To ensure that the lighting only activates when truly necessary, the IS 3180 features adjustable ambient light sensitivity. With a convenient adjustment knob, the activation level can be set continuously from 2 lux to 2000 lux. This means you can tailor the lighting to the specific light conditions of your environment.
Additionally, you can adjust the time setting so that the light remains on for a certain period after detecting movement. The time setting is adjustable from 5 seconds to 15 minutes, providing a flexible and user-friendly experience.
Other Features
- Maximum load:2000W
- IP rating:IP54, meaning the sensor is resistant to dust and splashes
- Ideal mounting height:2 meters
With the IS 3180-E PF AP WS, you are assured of a reliable and efficient motion detector that optimizes your lighting and saves energy. This product is an excellent choice for anyone looking for a smart solution for their lighting needs.
IS 3180-E PF AP WS Motion Detector
The IS 3180-E PF AP WS from Steinel is an advanced motion detector that is perfect for both indoor and outdoor applications. With its powerful functionality and smart design, this sensor provides a reliable solution for automatically turning on lighting when needed.
Sensor Features
This motion detector is equipped with a built-in infrared sensor that registers movements at an angle of 180 degrees, up to a distance of 20 meters. The sensor responds not only to movement but also to the body heat of people, effectively excluding disturbances such as wind, leaves, rain, and small animals. This makes the IS 3180 particularly suitable for use in various environments.
Adjustable Sensor Settings
To ensure that the lighting only activates when truly necessary, the IS 3180 features adjustable ambient light sensitivity. With a convenient adjustment knob, the activation level can be set continuously from 2 lux to 2000 lux. This means you can tailor the lighting to the specific light conditions of your environment.
Additionally, you can adjust the time setting so that the light remains on for a certain period after detecting movement. The time setting is adjustable from 5 seconds to 15 minutes, providing a flexible and user-friendly experience.
Other Features
- Maximum load:2000W
- IP rating:IP54, meaning the sensor is resistant to dust and splashes
- Ideal mounting height:2 meters
With the IS 3180-E PF AP WS, you are assured of a reliable and efficient motion detector that optimizes your lighting and saves energy. This product is an excellent choice for anyone looking for a smart solution for their lighting needs.
- Product number 68026
- Manufacturer product number 10508
- Material Plastics
- IP value 54
- Warranty 2
- Color White
- Dimensions (W) x (H) x (D) : 9.5 x 9.5 x 6.5 cm
