Description

Especially in areas that can become problematic for temperature-dependent infrared sensors, high-frequency technology is the perfect alternative. That is why the HF 3360 is the ideal solution if you want to automate the lighting in basement corridors with many corners, stairwells and parking garages. He registers the smallest movements safely and accurately and thus ensures perfect automatic light control? even in the stairwell over 2 floors. The HF 3360 is also ideal for all house entrance zones, because the light is switched when the sensor registers the opening door. Available as a mounting or installation variant and of course compatible with the standard connection types. European Article Number (EAN) 4007841033712 Implementation Motion detector Sensor type High frequency Angle of detection 360 ° with 140 ° opening angle Range Ø 1 - 8 m recommended mounting height 2-2.8 m Dimensions (H x W x D) 64 x Ø 124 mm Power supply 220 - 240 V, 50 / 60Hz Power 50-240 V, 10 A Self-learning function for response clarity yes Time setting 5 sec. - 15 min. impulse mode (approx. 2 sec.) Response brightness 2-1000 lx Degree of protection (IP) IP20 Temperature -20-50 ° C Housing UV-resistant plastic Model Potential free Variant Potential free - Installation round

HF 3360-R PF UP WS Motion Detector

The HF 3360-R PF UP WS from Steinel is an advanced motion detector that provides optimal lighting based on movement. Thanks to the built-in sensor, this detector registers movements in a 360-degree circle, up to a distance of 8 meters. This makes it an ideal choice for both indoor and outdoor use.

Sensor Features

This motion detector can be easily connected to a light source with a maximum power of 2000W. The infrared sensor is designed to respond to the body heat of people, effectively ignoring disturbances such as wind, leaves, rain, and small animals. This ensures that the light only turns on when it is truly needed.

Settings for Optimal Operation

The HF 3360 offers flexible settings to adjust the operation to your specific needs. With a convenient adjustment knob, the ambient light level can be set from 2 lux to 1000 lux. This means you can determine under which light conditions the sensor light should be activated. After detecting movement, the light remains on for an adjustable period, ranging from 5 seconds to 15 minutes. Additionally, the range can be continuously adjusted up to a maximum of 8 meters.

Other Features

The HF 3360 is made from UV-resistant plastic, ensuring a long lifespan and resistance to the elements. With an IP rating of IP20, this motion detector is suitable for various applications. The recommended mounting height is between 2 meters and 2.8 meters, ensuring optimal operation and coverage.

Benefits of the HF 3360-R PF UP WS

• 360-degree detection up to 8 meters
• Adjustable ambient light level (2 lux - 1000 lux)
• Adjustable duration (5 seconds - 15 minutes)
• UV-resistant plastic housing
• Maximum power of 2000W

With the HF 3360-R PF UP WS, you not only bring home an innovative motion detector but also a reliable solution for your lighting needs. Whether you want to create a safe environment or simply save energy, this motion detector is the right choice.
